| Technical Data | TP1200 Comfort | KP1200 Comfort |
|---|---|---|
| Hardware | ||
| Display | 12.1 inch TFT widescreen display, 16 Mio colors | |
| Resolution | 1280 x 800 px | |
| Control elements | Touch screen | Membrane Keypad (28 keys), 34 function keys with LED |
| User memory | 12 MB | |
| Interfaces | 2 x RJ 45 Ethernet for PROFINET 1 x RS 485/422 for PROFIBUS/MPI 2 x USB-host, 1 x USB- device 2 x SD card slot |
|
| Degree of protection | IP 65, NEMA 4x (front if mounted) / IP 20 rear | |
| Installation cutout | 310 x 221 mm (W x H) | 434 x 268 mm (W x H) |
| Front panel | 330 x 241 mm (W x H) | 454 x 289 mm (W x H) |
| Device depth | 63 mm | 63 mm |
| Software functions | ||
| Configuration software | WinCC Comfort (TIA Portal) or higher | |
| Messages | 4000 | |
| Message classes | 32 | |
| Process pictures | 500 | |
| Variables | 2048 | |
| Vector graphics | x | |
| Bar graphics | x | |
| Curve diagrams | f (t), f (x) | |
| Recipes | 300 | |
| Archiving | 50 | |
| Visual Basic Scripts | 100 | |
| Article No.: | 6AV2124-0MC01-0AX0 | 6AV2124-1MC01-0AX0 |
Tel : 02-990-1919
Mail: [email protected]
HMI SIEMENS COMFORT PANEL KP1200 and TP1200 Comfort
มีคนกำลังชมสินค้าชิ้นนี้เหมือนคุณอยู่ 47 คน
12 inch Panels with TFT color widescreen display
The KP1200 offers high-end performance for HMI applications that cannot do without mechanical keys.
The KP1200 Comfort is the successor of the Multi Panel MP 277 10 inch Key, it offers additional display space, a higher screen resolution and higher performance.
The TP1200 Comfort is the successor of the Multi Panel MP 277 10 inch Touch, it offers 22% additional display space, a higher screen resolution and higher performance.
