Specifications | PLC SIMATIC S7-1500 – SIPLUS CPUs
| CPU Module | ||||
|---|---|---|---|---|
| Model | Type | Number | Memory | Communication port PROFINET |
| SIPLUS CPU 1511-1 PN | SIPLUS standard CPUs | 6AG1511-1AK02-2AB0 | 1 MB | 2 slot |
| 6AG1511-1AK02-7AB0 | ||||
| SIPLUS CPU 1513-1 PN | 6AG1513-1AL02-2AB0 | 1.5 MB | ||
| 6AG1513-1AL02-7AB0 | ||||
| SIPLUS CPU 1516-3 PN / DP | 6AG1516-3AN01-2AB0 | 5 MB | 3 slot | |
| SIPLUS CPU 1518-4 PN / DP | 6AG1518-4AP00-4AB0 | 10 MB | 4 slot | |
| SIPLUS CPU 1518-4 PN / DP MFP | 6AG1518-4AX00-4AC0 | 20 MB | ||
| SIPLUS CPU 1511F-1 PN | SIPLUS fail-safe CPUs | 6AG1511-1FK01-2AB0 | 1 MB | 2 slot |
| SIPLUS CPU 1513F-1 PN | 6AG1513-1FL02-2AB0 | 1.5 MB | ||
| SIPLUS CPU 1515F-2 PN | 6AG1515-2FM01-2AB0 | 3 MB | 3 slot | |
| SIPLUS CPU 1516F-3 PN / DP | 6AG1516-3FN01-2AB0 | 5 MB | ||
| SIPLUS CPU 1518F-4 PN / DP | 6AG1518-4FP00-4AB0 | 20 MB | 4 slot | |
Properties | PLC SIMATIC S7-1500 – SIPLUS CPUs
| PLC SIMATIC S7-1500 | SIPLUS CPUs |
|---|---|
| Max. PN IO IRT | 2 Port |
| Max. PN IO RT | 1 Port |
| Max. PN (Gbit) | 1 Port |
| Max. Profibus DP | 1 Interface |
| Program / Data capacity | 150 KB / 1 MB to 4 / 20 MB |
| Bit-Performance | 60 ns to 1 ns |
| Numbers of connection | 96 to 384 |
| Number of motion control resources | 800 to 10240 |
| Max. Number of I/O modules | 16384 |
