OMRON C200H series

C200Hα PLC — System Specifications
ITEM SPECIFICATIONS
Supply voltage AC power supply: 100 to 120/200 to 240 VAC selectable 50/60 Hz
DC power supply: 24 VDC
Operating voltage range AC power supply: 85 to 132/170 to 264 VAC
DC power supply: 19.2 to 28.8 VDC
Power consumption AC power supply: 120 VA max.
DC power supply: 50 W max.
Surge current 30 A max.
Output capacity 4.6 A, 5 VDC; 0.6 A, 26 VDC; 0.8 A, 24 VDC+10%/–20% (C200HW-PA204S only)
Insulation resistance 20 MΩ between AC terminals and the GR terminal at 500 VDC (see note 1)
Dielectric strength 2,300 VAC at 50/60 Hz for 1 minute between AC terminals and housing; 1,000 VAC at 50/60 Hz for 1 minute between DC terminals and housing. Leakage current: 10 mA max. (see note 1)
Noise immunity 1,500 Vp-p, pulse width: 100 ns to 1 µs, rise time: 1 ns pulse (by noise simulator)
Vibration 10 to 57 Hz; 0.075 mm amplitude, 57 to 150 Hz; acceleration: 1 G, in X, Y, and Z directions, for 80 minutes each (sweep time 8
min x 10 sweeps = 80 min); (When mounted on DIN track, 2 to 55 Hz, 0.3 G, in X, Y, and Z directions for 20 minutes each)
Shock 15G (147 m/s2) in X, Y, and Z directions, 3 times each
Ambient temperature Operating: 0 to 55°C (32°to 131.0°F)
Storage: –20 to 75°C (-4.0 to 167.0°F) without battery
Humidity 10% to 90% (without condensation)
Atmosphere Must be free of corrosive gases
Grounding Less than 100 Ω
Enclosure rating IEC IP30 (mounted in a panel)
Weight 6 kg max. (CPU: 315 g max., Power Supply Module: 510 g max., Backplane: 445 g to 1040 g)
