PLC SIMATIC S7-1500 – Profibus

Communications module expands the SIMATIC S7-1500 controller to include a PROFIBUS connection for communication with lower-level PROFIBUS devices in bandwidths from 9.6 kbps to 12 Mbps. The module can also be used to implement separate PROFIBUS lines, in other words, to control a number of different field devices via a number of PROFIBUS segments. The CM 1542-5 assumes all communication tasks, thus reducing the CPU workload. Communications module suitable for S7 communication as well as for conventional PROFIBUS communication. This makes it possible to establish communication between the S7-1500 controller and other devices, for example those from the SIMATIC S7-300/400 range.

PROFIBUS DP master or DP slave with electrical interface for connecting the SIMATIC S7-1500 to PROFIBUS at up to 12 Mbps (including 45.45 kbps)

1. Communication services
– PROFIBUS DP
– PG/OP communication
– S7 communication
– Open user communication (SEND/RECEIVE) via FDL
2. Time synchronization
3. Simple programming and configuration over PROFIBUS
4. Cross-network PG communication using S7 routing
5. Module replacement without a PG
6. Data record routing (PROFIBUS DP)
